Specifications :
| Model | Tiger-X |
| Driving | Electric |
| Tensioning | Electric |
| Rated Power | 18.5-25KW |
| Voltage | AC380±10% 50Hz / Customized |
| Temperature | -15 - 40℃ |
| Speed | 26m/s |
| Max Tension | 230KG |
| OD of Driving Pulley | 500mm |
| Track Length | 1300mm |
| Dimension(mm) | 2200*800*880 |
| Net Weight | 350KG |
Features :
Directly driven by electric motor, without power loss during work;
Easy and simple to handle and maintain;
Avoid anchoring before starting work
Can be moved by one person
